DTD201Z

18V Brushless 4-Stage Impact Driver

  • DTD201Z - 18V Brushless 4-Stage Impact Driver
  • DTD201Z - 18V Brushless 4-Stage Impact Driver
  • DTD201Z - 18V Brushless 4-Stage Impact Driver
  • DTD201Z - 18V Brushless 4-Stage Impact Driver
  • DTD201Z - 18V Brushless 4-Stage Impact Driver
  • DTD201Z - 18V Brushless 4-Stage Impact Driver

Features

    • Maximum fastening torque of 210Nm for heavy duty applications
    • 4 stage speed selection & T-mode (for thin metal sheets) for added control
    • Precision fastening with enhanced anvil stability for less bit wobble
    • Compact length at only 121mm, ideal for working in tight spaces
    • Precision fastening with enhanced anvil stability for less bit wobble
Where To Buy
Information Booklet
Product Manual
Parts Diagram
  • Drive shank
    6.35mm (1/4") Hex
    Impact rate
    Max: 0 - 4,400rpm/Hard: 0 - 4,200rpm/ Medium: 0 - 3,600rpm/ Soft: 0 - 2,000rpm
    Max. capacities high tensile bolt
    M5 -M14
    Max. capacities standard bolt
    M5 -M16
    Max. tightening torque
    Max.: 210Nm/ Hard: 190Nm/ Med: 150Nm/ Soft: 20Nm
    No load speed
    Max: 0 - 3,700rpm/ Hard: 0 - 3,200rpm/ Medium: 0 - 2,100rpm/ Soft: 0 - 1,100rpm
    Overall length
    121mm
    Skin weight
    1.0kg
    Voltage
    18V
    Weight (with battery)
    1.7kg (BL1860B)

  • Truss head screw M4X12 (266622-8)

    Hook (346317-0)
